Jonsbo D31 Mesh Screen - Micro-ATX Case Tempared Glass - Black
![Jonsbo D31 Mesh Screen - Micro-ATX Case Tempared Glass - Black [D31_MESH_BLACK_SC] Εικόνα 1](https://static.msystems.gr/photos/big_photos/47094.jpg)
![Jonsbo D31 Mesh Screen - Micro-ATX Case Tempared Glass - Black [D31_MESH_BLACK_SC] Εικόνα 2](https://static.msystems.gr/photos/big_photos/47094.1.jpg)
![Jonsbo D31 Mesh Screen - Micro-ATX Case Tempared Glass - Black [D31_MESH_BLACK_SC] Εικόνα 3](https://static.msystems.gr/photos/big_photos/47094.2.jpg)
![Jonsbo D31 Mesh Screen - Micro-ATX Case Tempared Glass - Black [D31_MESH_BLACK_SC] Εικόνα 4](https://static.msystems.gr/photos/big_photos/47094.3.jpg)
Χωρίς ΦΠΑ: - €
Πληροφορίες
Δόσεις
Buy Now - Pay Later
Jonsbo D31: The versatile mATX case
With the D31, Jonsbo presents a micro ATX case from its Pine Cones series that is as compact and elegant as it is versatile. It can easily accommodate the latest gaming hardware. Whether you prefer air or water cooling, the Jonsbo D31 offers plenty of space for both. Depending on the size of your GPU and how many fans you need, you can position the PSU on the front to suit your needs.
Compact and elegant gaming case for Micro-ATX motherboards
Mesh front panel for improved airflow, tempered glass side panel
Designed for vertical airflow with up to eight possible fans
Vertically adjustable power supply for longer graphics cards
GPU's can be at least 330 mm, and up to 400 mm long
Room for up to two 360 mm radiators simultaneously
Equipped with an 8-inch display, to show system information for example
Mini-HDMI to HDMI cable and USB-C to USB-A cable for the display included
High-end gaming hardware: Well presented
The interior of the Jonsbo D31 is clearly visible through the tempered glass side panel. In addition to the mATX mainboard, a graphics card with a minimum length of 330 mm and a maximum length of 400 mm can be installed inside. The PSU behind a shroud can be moved vertically by 140 mm in four steps. There is space for two SSDs behind the motherboard bracket. There is also plenty of space for cable management. An HDD can be placed on the floor at the front, forfeiting a third fan.
| Κατασκευαστής | Jonsbo |
| Μοντέλο | D31 Mesh Screen - Micro-ATX Case Tempared Glass - Black |
| Part Number | D31_MESH_BLACK_SC |
| Κατηγορία | Κουτιά |
| Μέγεθος μητρικής | Mini-ITX Micro ATX |
| Μέγεθος | Mini Tower |
| Tροφοδοτικό | Χωρίς Τροφοδοτικό |
| Πρόσθετα Χαρακτηριστικά | Οθόνη 8" Color TFT- LCD - Resolution: 1280x800 - Response Time：30ms - Brightness：300cd/m2 - Contrast Ratio：1000:1 |
| Εσωτερικές Θέσεις | 2x 2.5" 1x 3.5" |
| Front Panel I/Os | 1x USB 3.0 1x USB 3.2 Type-C Combo Jack |
| Χρώμα | Black |
| Λοιπά στοιχεία | Dimensions: 205 * 363 * 452 mm Weight: 6.4KG PCI expansion slots：4 Fan Support Top: 120mm *3 or 140mm *2 Rear: 120mm *1 Bottom: 120mm *3 or 140mm *2 Front: 120mm *1 Radiator Support Top: 240/ 280/ 360 *1 Rear: 120 *1 Bottom: 240/ 360 *1 Clearance CPU Cooler Height: 168mm GPU length: 330 ~ 400mm Power Supply: ATX Display Dimensions: 24.6 * 131.7 * 205.3 mm Colors：16.7M Resolution：1280 * 800 Response Time：30ms(Typ.) Brightness：300cd/m2(Typ.) Contrast Ratio：1000（Typ. I/O：MINI-HDMI *1 (Video Signal), TYPE-C *1 Refresh Rate (max.)：60Hz Working Temperture：0-50℃ |
| Εγγύηση | 2 Έτη |
